Gbona Awọn ọja
Iwapọ ati Ile-iṣẹ Iyara Kekere Gbẹkẹle fun Iṣẹ Laabu Lojoojumọ
| ohun elo: | Awọn ile-iwosan, Awọn ile-iwosan ti ogbo, Awọn ile-iṣẹ ounjẹ, Awọn ile-ẹkọ giga & awọn ile-iwe giga, Awọn ile-iwosan elegbogi, Awọn ile-iṣẹ aṣa sẹẹli, Awọn ibudo ọmọde |
| Max. Iyara | 6000 irọlẹ |
| O pọju.RCF | 4752xg |
| O pọju.Agbara | 4 * 400ml golifu jade ẹrọ iyipo |
| Rotors ti o baamu | Awọn rotors igun ti o wa titi; Gbigbe awọn rotors; Microplate iyipo |
| àpapọ | LED |
| Awoṣe Number: | TDZ5-WS |
| iwe eri: | CE, ISO13485,ISO9001,SFDA |
| atilẹyin ọja | Atilẹyin ọdun 1 fun gbogbo ẹrọ, atilẹyin ọja ọdun 3 fun compressor ati atilẹyin ọja ọdun 5 fun motor. Awọn ẹya aropo ọfẹ ati sowo laarin atilẹyin ọja. |
- Apejuwe
- Fidio
- imọ ni pato
- Rotors ati Awọn ẹya ẹrọ
- ifigagbaga Anfani
Awọn benchtop centrifuge TDZ5-WS daapọ to ti ni ilọsiwaju ọna ẹrọ pẹlu ga agbara.
O wa pẹlu ọpọlọpọ golifu-jade ati awọn rotors igun ti o wa titi, pẹlu ọpọlọpọ awọn buckets ati awọn alamuuṣẹ. Awọn ẹya ara ẹrọ lọpọlọpọ le gba awọn tubes ati awọn filasi lati 2 milimita si 400 milimita bii microtiter ati awọn awo jinde.
TDZ5-WS centrifuge iyara kekere jẹ o dara fun ọpọlọpọ awọn agbegbe ohun elo ni awọn iwadii ile-iwosan, oogun ti ogbo, awọn oogun, itupalẹ ayika ati iṣelọpọ ile-iṣẹ, ati awọn ile-ẹkọ giga ati awọn ohun elo iwadii.
Design
● Irin ile, ideri irin, ati 304 # alagbara, irin centrifuge iyẹwu ni o wa autoclave-anfani ati ki o sooro detergents ati disinfection olomi.
● Ferese akiyesi lori ideri fun isọdọtun iyara ati wiwọn ariwo.
● Microprocessor Iṣakoso pẹlu igbohunsafẹfẹ iyipada AC motor drive
● LED Ṣe afihan awọn ipele ti Iyara, Aago, RCF, Rotors, Eto (Iranti), isare & Alaye idinku ati alaye koodu aṣiṣe.
● Oruka edidi awọn ipele meji ti a ṣe fun ideri centrifuge ati ohun elo lati tọju idaduro to dara pipẹ.
Onirọrun aṣamulo
● Eto ati ipamọ, fipamọ to awọn eto 30 ati pese iraye si olumulo taara pẹlu fifipamọ bọtini bọtini kan. Paramita ti o fipamọ: apapo wa ninu iranti paapaa lẹhin ti centrifugation ti wa ni pipa.
● Pese awọn oṣuwọn isare 10 ati rampu braking 10, lati yago fun imunadoko isọdọtun keji, pẹlu ipa centrifugation to dara julọ.
● Titiipa ideri aifọwọyi ati didimu lakoko ṣiṣe rotor
● Awọn rotors paṣipaarọ ni irọrun
● Laasigbotitusita aifọwọyi pẹlu itọkasi koodu aṣiṣe ati itaniji loju iboju.
● “Dẹkun” imọ-ẹrọ itọsi. Ariwo ipele kekere ju 55 decibel ni iyara iyipo ti o ga julọ.
● Awọn oluyipada ti 0.5-500 milimita wa.
Abo
● Ti ṣejade ni ibamu si awọn ilana aabo agbaye (fun apẹẹrẹ IEC 61010)
● Aabo Itanna ideri interlock, ilekun ko le ṣii nigbati rotor nṣiṣẹ ati ẹrọ kii yoo ṣiṣẹ nigbati ideri ṣii ati koodu aṣiṣe han.
● Itusilẹ ideri ideri pajawiri nigbati agbara ikuna.
● Gas mitari fun ideri ju Idaabobo.
● Awọn aabo aabo ni a ṣe fun iyara ti o kọja, lori alapapo (moto, iyẹwu), aiṣedeede ati bẹbẹ lọ lati rii daju aabo ẹrọ eniyan.
| Iwọn iyara (rpm) | 0-6000rpm adijositabulu | Iyara iyara | 10rpm |
| O pọju agbara (milimita) | 4 * 400ml | Iwọn RCF (xg) | 0-4752xg adijositabulu |
| àpapọ | LED | Akoko ibiti | Iṣẹju 0-99 |
| Ariwo (dBA) | ≦55dB(A) | Isare / Deceleration awọn ošuwọn | 1-- 10 |
| Apa miran (mm) | 580x440x360mm | motor | Motor Igbohunsafẹfẹ Converter |
| Iwọn apapọ (laisi ẹrọ iyipo) | 40KGS | ipese agbara | AC220V/230V,50HZ,10A,500W |
| No. | ohun | agbara | Max.iyara | O pọju.RCF | akọsilẹ |
NO.1
|
Rotor igun | 12 × 15 milimita | 6000r / min | 4588xg |
PP / PC tube |
| ti nmu badọgba | 12 × 2 milimita | ||||
NO.2
|
Rotor Swing | Irin fireemu iyipo | 5000r / min | 4752xg | |
| Fireemu golifu | 4 × 100 milimita | PP / PC tube | |||
| Fireemu golifu | 4 × 50 milimita | PP / PC tube | |||
| ti nmu badọgba | 4 × 15 / 10ml | PP / PC tube | |||
NO.3
|
Rotor Swing | Irin fireemu iyipo | 4000r / min | 3041xg | |
| Fireemu golifu | 4×2×100ml | PP / PC tube | |||
| Fireemu golifu | 4×2×50ml | PP / PC tube | |||
| ti nmu badọgba | 8 × 15 / 10ml | PP / PC tube | |||
| Fireemu golifu | 4×8×15/10/5ml | PP/PC/Vacuum ẹjẹ gbigba awọn tubes | |||
| Oko | 4× 12× 5/2ml | Igbale ẹjẹ gbigba awọn tubes | |||
NO.4
|
Rotor Swing | 4× 18× 5/2ml | 4000r / min | 2773xg | Igbale ẹjẹ gbigba awọn tubes |
NO.5
|
Golifu garawa | 4 × 400 milimita | 4000r / min | 3049xg | garawa onigun |
| ti nmu badọgba | 4× 16× 5/2ml | Igbale ẹjẹ gbigba awọn tubes | |||
| ti nmu badọgba | 4× 9× 15/10ml | PP / PC tube | |||
| ti nmu badọgba | 4×4×50ml | PP / PC tube | |||
| ti nmu badọgba | 4 × 100 milimita | PP / PC tube | |||
NO.6
|
Golifu garawa | 4 × 250 milimita | 4000r / min | 3049xg | garawa yika |
| ti nmu badọgba | 4× 9× 5/2ml | Igbale ẹjẹ gbigba awọn tubes | |||
| ti nmu badọgba | 4× 5× 15/10ml | PP / PC tube | |||
| ti nmu badọgba | 4 × 50 milimita | PP / PC tube | |||
| ti nmu badọgba | 4 × 100 milimita | PP / PC tube | |||
| ti nmu badọgba | 4×9×1.5ml | PP / PC tube | |||
NO.7
|
Microplate iyipo | 2× 2× 96 iho | 4200r / min | 2860xg | garawa onigun |
| ti nmu badọgba | 2×32×1.5ml | PP / PC tube | |||
 | |||||
1. Olupese centrifuge ọjọgbọn, idiyele ifigagbaga.
2. ISO9001, ISO13485, CE, Iwe-ẹri SFDA, gbogbo awọn ẹrọ gba idanwo didara ti o muna ati apoti ti o dara ṣaaju gbigbe.
3. Atilẹyin imọ-ẹrọ igba pipẹ ati iṣẹ alabara ọjọgbọn ni gbogbo ipele ti awọn tita ọja, ifijiṣẹ ati iṣiṣẹ.Our oṣiṣẹ ti o ga julọ ati ẹgbẹ iṣẹ ti o ni iriri ti n pese fun ọ ni ipele alailẹgbẹ ti atilẹyin fun rira rẹ fun gbogbo igbesi aye rẹ.
4. A tun le pese awọn iṣeduro ti a ṣe adani fun awọn ibeere pataki ti awọn onibara.
5. Agbara pẹlu ẹgbẹ ti o munadoko ti awọn onimọ-ẹrọ ti o ṣe atilẹyin nipasẹ awọn ọdun ti iriri ni awọn aaye wọn, ile-iṣẹ naa ṣe idaniloju ọja kọọkan ati gbogbo ọja ti o lọ kuro ni ile-iṣẹ iṣelọpọ jẹ titi de ami ni gbogbo awọn ọna.
